Skip to content | Specification | C8004CNC(NO/PC/PO)BC05G | C8006CNC(NO/PC/PO)BC05G | C8008CNC(NO/PC/PO)BC05G | C8024CNC(NO/PC/PO)BC05G |
| Number of optical axes | 4 | 6 | 8 | 24 |
| Optical axis spacing | 20mm | |||
| Interface Size | 30mm*30mm | |||
| Signal output | NPN/PNP/Relay | |||
| Protective height | 70mm-2994mm | |||
| Detection distance | 0.1 ～ 5m | |||
| Sensitivity adjustment | Non-adjustable | |||
| Response time | 10 ～ 34ms max | |||
| Reset time | Output reset time＜ 200ms | |||
| Supply voltage | 24±10%VDC；Rippl（continuous wave）±20% P-P max | |||
| Current consumption | 30mA | |||
| Residual voltage | ≤1V | |||
| Protection circuit | Polarity protection and instantaneous reverse polarity protection | |||
| Indicator light | Digital tube indicator | |||
| Ambient illuminance | Incandescent: Spot intensity under 3,000Lx; Sunlight: Spot intensity: under 10,000Lx ( Angle of incidence ≥ 5° ) | |||
| Temperature range | Operating: -5 to +55°C (no icing, condensation); Storage: -30 to +80°C (no icing, condensation) | |||
| Humidity range | Operating, storage: 25 to 85% (no condensation) | |||
| EMC Standard | ESD：8KVAirchage(level3)/EN-61000-4-2;Burettest:2KV/EN61000-4-4 RF Interferenoe:10V/M/ENV50140 | |||
| Connection Method | Cable Inserts | |||
| Material | Aluminium alloy, top and bottom cover: reinforced nylon | |||
| Installation | Slotted installation | |||
