Skip to content | Specification | HHS1（JS14S) | HHS1-1(DH14S) | HHS1(JS14S) Improved | HHS1-1 (DH14S) Improved |
| Operating power | DC24V;AC24V,AC220V,AC380V | |||
| Delay range | 0.01s~99h99m | |||
| Repetition error | ≤ 1% | |||
| Working Mode | Power-on delay | |||
| Timing mode | Positive timing, digital tube display | |||
| Contact form | Two sets of delay with reset pause function | Two delay with reset pause (11 pins) | ||
| Contact capacity | 3A AC250V (resistive) | |||
| Dimension | 52×104×114mm | |||
| Opening size | 45×77mm | |||
| Installation | Panel type | |||
| Temperature range | -5°-40°C | |||
| Altitude | ≤2000m | |||
HHS1 series time relays belong to the energized time-delay type and are suitablefor use as time-delay elements in control circuits with AC 50Hz,operating voltagesof 380V and below,or DC operating woltages of 24V,to connect or break circuits atpreset times.
| Specification | HHS1 |
| Rated Supply Voltage | AC220V |
| Working mode | Power-on delay |
| Delay range | 0.01S~99h99m |
| Timing mode | countdown,digital tube display |
| Contact form | two sets of delay(8 pins) |
| Dimensions | 52×104×99mm |
| Opening size | 45×77mm |
| Installation mode | Panel type |
