Model specification: CJX2-80, CJX2-95
Rated working current (Ie): 80A, 95A
Rated insulation voltage (Ui): 690V
Rated working voltage: 400V
Rated control voltage: AC: 24V, 36V, 48V, 96V, 110V, 127V, 220V, 380V
Ambient temperature: upper limit temperature: +40℃; lower limit temperature: -5℃;
Auxiliary contact: 11 (one normally closed auxiliary contact + one normally open auxiliary contact/1NC+NO);
Use category: AC-3, AC-4
Installation method: vertical installation (screw installation, 35mm/75mm standard rail)
Accessories: auxiliary contact group, air delay contact, mechanical interlocking mechanism
Dimensions (mm): 96×129×127
Installation dimensions (mm): 40×100/110
Specification | CJX2 Series |
Rated operating current (Ie) | 80A、95A |
Rated insulation voltage (Ui) | 690V |
Rated Working Voltage | 400V |
Rated control voltage | AC:24V、36V、48V、96V、110V、127V、220V、380V |
Environmental temperature | Upper limit temperature: +40°C; lower limit temperature: -5°C; |
Auxiliary Contacts | 11 (one normally closed auxiliary contact + one normally open auxiliary contact/1NC+NO); |
Category of use | AC-3、AC-4 |
Installation | Vertical mounting (screw mount, 35mm/75mm standard clamp rail) |
ANNEXES | Auxiliary contact set, air delay contacts, mechanical interlocking mechanism |
Overall Dimension(mm) | 96×129×127 |
Mounting Dimension(mm) | 40×100/110 |
