Measuring signal: AC current (AC0~5A); AC voltage (AC0~500V)
Other specifications can be customized
Measurement error: ≤0.5 level
Display mode: Manually switch to display the measured primary power or the output power
Display range: Primary power 0~9999 can be freely set
Transmitter output: DC0~10mA/0~20mA/4~20mA (freely set)
Load impedance: ≤350Ω
Working power supply: AC220V, AC380V
Dimensions: 79×50×105mm
Installation method: Standard DIN rail installation, fixed installation
Typical applications: Used for transmission, isolation and measurement of large current and high voltage in explosion-proof control boxes, distribution cabinets, transformer boxes and other equipment
PAS series | ||
Model | PAS-A | PAS-V |
Measurement signal | AC current (AC0~5A) | AC voltage (AC0~500V) |
Measurement error | ≤ 0.5 class | |
Display mode | It can be manually switched to display the measured primary electric quantity or transmitting output electric quantity | |
Display range | Primary electric quantity 0~9999 settable | |
Transmission output | DC0~10mA/0~20mA, 4~20mA (settable) | |
Load impedance | ≤ 350Ω | |
Supply voltage | AC220V or AC380V | |
Dimension | 79×50×105mm | |
Installation method | Standard DIN rail installation, fixed installation | |
Typical application | Used for isolation and measurement of high current and high voltage transmission in explosion-proof control boxes, distribution |
