Output mode: single output, dual output, analog output, single output
Output selection: LIGHT-ON/DARK-ON (switch selection)
Protection circuit: power supply reverse polarity protection, overcurrent protection, overvoltage protection
Detection method: light intensity (area detection, automatic sensitivity tracking function)
Delay function: disconnect delay timer/on delay timer/
single timer/on delay single timer
Material: polycarbonate
Specification | C6-F21 |
Output Signal Type | NPN/PNP |
Production Process | SemiConductor Integrated |
Material | Plastic |
Accuracy Grade | 0.1G |
IP Rating | IP67 |
Light | Red Modulated Light 625nm |
Detection Method | Light Intensity |
Response Time | 200us/24ms/25us |
Timer Function | One Shot |
Timing range | 1 ~ 9999ms |
Temperature range | -20℃~ 55℃ |
Current consumption | ≤ 30mA |
Basic value tracking | Standard |
Practical Functions | Parameter initialisation/key lock/threshold two points |
