Working power supply: AC/DC24V;AC220V;AC/DC100-240V;AC380V
Working mode: positive counting, 4-digit LED display
Counting speed: 100 times/second
Counting range: 1-9999
Input signal: contact signal, PNP normally open photoelectric/proximity switch
Output mode: N or C standard
Power failure memory: 10 years
Contact form: a set of normally open and normally closed contacts
Contact capacity: 3A AC250V (resistive)
Dimensions: 72×72×81mm
Opening size: 68×68mm
Installation method: panel type
Working power supply: AC/DC24V;AC220V;AC/DC100-240V;AC380V
Working mode: forward counting, backward counting
Counting speed: high frequency 1000 times/second; low frequency 30 times/second
Counting range: (1-999999)×1,×10,×100 times
Input signal: contact signal, PNP normally open photoelectric/proximity switch
Output mode: N, C, F, X, R multi-standard
Power failure memory: 10 years
Contact form: a group of normally open and normally closed contacts
Contact capacity: 3A AC250V (resistive)
Dimensions: 72×72×81mm
Opening size: 68×68mm
Installation method: panel type
Remarks: T standard needs to be customized
Specification | JDM9-4A | JDM9-4 | JDM9-6 |
Operating power | AC/DC 24V;AC220V;AC/DC 100-240V;AC380V | ||
Operating Mode | Positive counting | Positive count, 4-digit LED display | Positive counting, reverse counting |
Counting speed | 10, 30, 100, 300 counts/sec. | 100 counts / sec | High frequency 1000 times/second; Low frequency 30 times/second |
Counting Range | 1-9999 | (1-999999)×1、×10、×100 | |
Input signal | Contact signals, normally open photoelectric / proximity switches | Contact signal, PNP normally open photoelectric/proximity switches | |
Contact capacity | 3A AC250V (resistive) | ||
Output mode | N 、 C | N、C、F、X、R | |
Temperature range | -5°-40°C | ||
Ith | 5A | ||
Ui | 400V | ||
Uimp | 2.5KV | ||
Ue/Ui | Rated working voltage Ue/rated working current Ie:AC-15 Ue:AC250V,Ie:3A for each category of use. | ||
Dimensions | 72×72×78mm | 72×72×81mm | 72×72×81mm |
Opening dimensions | 68×68mm | 68×68mm | 68×68mm |
Installation | panel mounted |
