Skip to content | Specification | HHS3 | HHS3G | HHS3C（AH2-N） | HHS3R-N | HHS3R-Y |
| Operating power | AC380V,AC220V,AC110V,AC36V,AC24V, 50Hz;DC24V | ||||
| Operation Mode | Power-on delay | Ryelease delay | Power-on delay with momentary contact | Cyclic delay | |
| Delay Range | 1s、3s、5s、10s、30s、60s、3m、5m、10m、30m、60m、3h、5h、10h | A:1s/10s/1m/10m; B:3s/30s/3m/30m; C:6s/60s/6m/60m; D:1m/10m/1h/10h;:3m/30m/3h/30h; | |||
| Repetition error | ≤1% | ||||
| Contact numbers | 2 sets of delayed transitions | 1 set of delayed transitions 1 set of instantaneous transitions | 2 sets of delayed transitions | ||
| Contact capacity | 3A AC250V (resistive) | ||||
| Temperature range | -5°-40°C | ||||
| Altitude | ≤2000m | ||||
| Humidity | The relative humidity of the air is <50% at a maximum temperature of 40°C at the installation site, higher relative humidity may be permitted at lower temperatures, e.g. up to 90% at 20°C. Special measures should be taken for occasional condensation due to temperature changes. | ||||
| Installation | Panel Type, Rail Type，Installation type | ||||
| Conventional heating current Ith | 5A | ||||
| Rated insulation voltage Ui | 400V | ||||
| Rated impulse withstand voltage Uimp | 2.5KV | ||||
| Ue/Ie | Rated Working Voltage Ue/Rated Working Current Ie:AC-15 Ue:AC250V,Ie:3A in each category of use. | ||||
