Liquid Level Relay C61F Series

MOQ : 100

Working power supply: AC220V, AC380V
Working mode: water supply and drainage
Water control distance: ≤ 100 meters
Contact form: a set of normally open and normally closed contacts
Contact capacity: 3A AC250V (resistive)
Dimensions: 40×55×79mm
Installation method: with different sockets and accessories, it can be installed in device type, panel type and 35mm guide rail

C61F-GP

Specification	C61F-GP
Working Power	AC380V, 220V, 110V, 36V, 24V50Hz: DC24V, the allowable voltage fluctuation range is (85%~110%) Ue.
Working mode	Water Supply and Drainage
Water control distance	≤ 100 metres
Contact form	a set of normally open and normally closed contacts
Contact capacity	3A AC250V (resistive)
Installation	Unit, panel and 35mm rail mounting with different sockets and accessories
Ith	3A
Ui	380V
Uimp	4KV
Ue/Ie	Rated working voltage Ue/rated working current Ie:AC-15 Ue:AC250V,Ie:3A for each category of use.
Dimensions	40×55×79mm
