Skip to content | Speicification | LJA series |
| Return Difference | Less than 15 % of detection distance |
| Detectable objects | Magnetic metals (shorter detection distances for non-magnetic metals) |
| Supply Voltage | DC ：Rated voltage DC12~24V (use range voltage DC10~30V);AC：M8:AC90~250V,M12-M30:AC24~250V |
| Operating current | Load current ≤200mA |
| Residual voltage | NPN ：≤ 1.5V;PNP ：≤ 2.5V; DC 2-wire：≤ 4V; AC 2-wire：≤ 7V |
| Leakage current | When 24VDC, max 0.1mA |
| Protection circuit | DC: polarity, overcurrent protection; AC: surge absorption protection |
| Indicator light | Dual light display: power indicator green, action indicator red |
| Temperature range | Operating: -25 to +70°C (no icing, condensation); Storage: -40 to +85°C (no icing, condensation) |
| Humidity range | Operation, storage: 35～95% (no condensation） |
| Temperature effect (drift) | -25～+70℃ temperature range, the detection distance is within ±10% of the detection distance at +23℃ |
| Protective structure | IP67 |
| Housing Material | Chrome Plated Brass |
| Sensing surface material | PBT |
