Working power supply: AC220V 50Hz
Rated power: 15W, 25W, 40W, 60W, 90W, 120W, 180W, 200W, 250W
Speed range: 90~1400r/min 50Hz; 90~2800r/min 60Hz
Control mode: Forward/reverse selectable:
COM and CW are connected for forward rotation, COM and CCW are connected for reverse rotation
Applicable scope: YYPJ, YCJT, YYCJ and other series of five-wire motors with speed measuring wires
Dimensions: 65×155×162mm
Opening size: 82×54mm 90-2×Φ4.5mm
Installation method: Panel screw installation
Remarks: With soft start and stepless speed regulation functions, square plug and flat plug are available, and the conventional factory is flat plug
Working power supply: AC220V 50Hz
Rated power: 15W, 25W, 40W, 60W, 90W, 120W, 180W, 200W, 250W
Speed range: 90~1400 rpm 50Hz; 90~1600 rpm 60Hz
Control mode: Forward/reverse selectable:
COM and CW are connected for forward rotation, COM and CCW are connected for reverse rotation
Applicable scope: YYDJ, YCJT, YYCJ, YCJFK series five-wire motor with speed measuring line
Dimensions: 60×99.6×104.2mm
Opening size: 81×53mm 90.5-2×Φ4.5mm
Installation method: Panel screw installation
Remarks: With soft start and stepless speed regulation functions, square, flat and C-shaped plugs are available, and the conventional factory is flat plug
US series | |
Model | US-52A |
Supply voltage | AC220V 50Hz |
Rated power | 15W, 25W, 40W, 60W, 90W 120W, 180W, 200W, 250W |
Speed regulation range | 90~1400 rpm 50Hz; 90~1600 rpm 60Hz |
Control mode | Forward/reverse optional: Connecting COM to CW for forward rotation, connecting COM to CCW for reverse |
Application scope | YYDJ, YCJT, YYCJ, YCJFK series five-wire motors with speed measuring wire |
Dimension | 60×99.6×104.2mm |
Hole size | 81×53mm 90.5-2×Φ4.5mm |
Installation method | Panel screw installation |
