Solid-State Relay HHG1D Series

MOQ : 720

Control voltage: 3-32VDC
Control current: 6-25mA
Load voltage: 22: 24-240VAC, 38: 24-440VAC
Load current: 3A, 4A
On-state voltage drop: AC≤1.6VAC
On-off time: AC≤10ms
Off-state leakage current AC≤10mA
Dielectric withstand voltage: ≥ 1500VAC
Ambient temperature: -30~80℃
Dimensions: 43×12×25.5mm
Installation form: single in-line plug-in
Description: Install next to the heat dissipation window with good ventilation

Control voltage: 3-32VDC
Control current: 6-25mA
Load voltage: 22: 24-240VAC, 38: 24-440VAC
Load current: 5A (with heat sink)
On-state voltage drop: AC≤1.6VAC
On-off time: AC≤10ms
Off-state leakage current: AC≤10mA
Dielectric withstand voltage: ≥ 1500VAC
Ambient temperature: -30~80℃
Dimensions: 43×12×34mm
Installation form: single in-line plug-in
Description: Install next to the heat dissipation window with good ventilation

HHG1D-1/032F-22

HHG1D Series
Model	HHG1D-1/032F-22(SSR-DA)
Control voltage	3-32VDC
Control current	6-25mA
Load voltage	22: 24-240VAC 38: 24-440VAC
Load current	5A (with heat dissipation plate)	3A、4A
On-state voltage drop	AC ≤ 1.6VAC
On-off time	AC ≤ 10ms
Off-state leakage current	AC ≤ 10mA
Dielectric strength	≥ 1500VAC
Ambient temp.	-30~80°C
Dimension	43×12×34mm	43×12×25.5mm
Installation form	Single line direct plug-in
Instruction	Installed next to well ventilated heat dissipation window

HHG1D-1/032F-38

HHG1D Series
Model	HHG1D-1/032F-38(SSR-DA)
Control voltage	3-32VDC
Control current	6-25mA
Load voltage	22: 24-240VAC 38: 24-440VAC
Load current	5A (with heat dissipation plate)	3A、4A
On-state voltage drop	AC ≤ 1.6VAC
On-off time	AC ≤ 10ms
Off-state leakage current	AC ≤ 10mA
Dielectric strength	≥ 1500VAC
Ambient temp.	-30~80°C
Dimension	43×12×34mm	43×12×25.5mm
Installation form	Single line direct plug-in
Instruction	Installed next to well ventilated heat dissipation window
