Time Relay HHS4 Series

Specification	HHS4	HHS4C	HHS4G	HHS4P	HHS4PA	HHS4PF
Operating power	AC380V,AC220V,AC127V,AC110V,AC36V,AC24V, 50Hz;DC24V
Movement Forms	Power-on delay	Power-on delay with momentary contact	Release delay	Power-on delay		Power Failure Delay
Delay Range	0.1s~1s、0.5s~5s、1s~10s、3s~30s、6s~60s、12s~120s、18s-180s、30s-300s、60s~600s、90s~900s、120s~1200s、180s~1800s、360s~3600s			0.01s~0.99s;0.1s~9.9s;1s~99s;0.1s~99.9s;1s~999s;0.1m~9.9m;1m~99m;1h~99h;	0.1s-99h	0.1s~9.9s1s~99s1s~199s
Number of contacts	Delay 2 conversion	Delay 1 transition with reset pause	Delay 2 conversion	Delay 2 conversion; delay 1 conversion, instantaneous 1 conversion		Delay 2 conversion
Repetition error	Er<1% when the delay range is greater than 1s; Dr<50ms when the delay range is less than 1s.					Er<5% when the delay range is greater than 1s. Dr<100ms when the delay range is less than 1s.
Contact capacity	3A AC250V (resistive)
Temperature range	-5°-40°C
Altitude	≤2000m
Humidity	The relative humidity of the air is ≤50% at a maximum temperature of 40°C at the installation site, higher relative humidity may be permitted at lower temperatures, e.g. up to 90% at 20°C. Special measures should be taken for occasional condensation due to temperature changes.
Installation	Device Type, Rail Type
Conventional heating current Ith	5A
Rated insulation voltage Ui	400V
Rated impulse withstand voltage Uimp	2.5KV
Ue/Ie	Rated Working Voltage Ue/Rated Working Current Ie:AC-15 Ue:AC250V,Ie:3A in each category of use.
