Skip to content | Specification | HHS11 |
| Operating power | DC24V;AC24V,AC36V,AC110V,AC220V,AC380V |
| Delay range | 0.01s~99.99s、1s~99m59s、1m~99h99m |
| Repetition error | Er<1% for delay range >1s; Er<50ms for delay range <1s |
| Working Mode | Power-on delay |
| Contact form | 1 set of momentary changeover contacts and 2 sets of delayed changeover contacts |
| Contact capacity | 3A AC250V (resistive) |
| Installation | Panel type |
| Temperature range | -5°-40°C |
| Altitude | ≤2000m |
| Humidity | The relative humidity of the air shall be ≤50 per cent at a maximum temperature of 40°C at the place of installation, and higher relative humidity may be permitted at lower temperatures, e.g. up to 90 per cent at 20°C. Special measures should be taken for occasional condensation due to temperature changes. |
| Ith | 5A |
| Ui | 400V |
| Uimp | 2.5KV |
| Ue/Ui | Rated working voltage Ue/rated working current Ie:AC-15 Ue:AC250V,Ie:3A for each category of use. |
