Skip to content | HHG1-0 series | |||||
| Model | HHG1-0/032F-06 100Z (SSR-DD) | HHG1-0/032F-20 2Z (SSR-DD) HHG1-0/032F-20 3Z (SSR-DD) HHG1-0/032F-20 4Z (SSR-DD) | HHG1-0/032F-20 1Z (SSR-DD) | HHG1-0/032F-20 5Z (SSR-DD) | HHG1-0/032F-20 10Z (SSR-DD) HHG1-0/032F-20 15Z (SSR-DD) HHG1-0/032F-20 20Z (SSR-DD) HHG1-0/032F-20 25Z (SSR-DD) HHG1-0/032F-20 30Z (SSR-DD) HHG1-0/032F-20 40Z (SSR-DD) HHG1-0/032F-20 60Z (SSR-DD) |
| Control voltage | 5-32VDC | 3-32VDC | 5-32VDC | ||
| Control current | 10-45mA | 6-25mA | 10-45mA | ||
| Load voltage | 06: 5-60VDC | 20: 12-250VDC | |||
| Load current | 100A | 2A, 3A, 4A | 1A | 5A | 10A, 15A, 20A, 25A, 30A, 40A, 60A |
| On-state voltage drop | ≤ 1.2VDC | DC ≤ 1.2V AC ≤ 1.6VAC | ≤ 1.2VDC | ||
| On-off time | ≤ 5ms | DC ≤ 5ms AC ≤ 10ms | ≤ 5ms | ||
| Off-state leakage current | ≤ 5mA | DC ≤ 5mA AC ≤ 10mA | ≤ 5mA | ||
| Dielectric strength | ≥ 2000VAC | ≥ 1500VAC | ≥ 2000VAC | ||
| Ambient temp. | -30~80°C | -30~80°C | -30~80°C | ||
| Dimension | 60×45×29mm | 34×26.5×18mm | 32.5×17.5×18.5mm | 42×31×20mm | 60×45×29mm |
| Installation form | Bolt installation | Dual line direct plug-in | Bolt installation | ||
| Instruction | A radiator must be installed for loads above 5A | Installed next to well ventilated heat dissipation window | A radiator must be installed for loads above 5A | ||
| HHG1-1 series | |||||
| Model | HHG1-1/032F-22 (SSR-DA) HHG1-1/032F-38 (SSR-DA) | HHG1-1/250F-22 (SSR-AA) HHG1-1/250F-38 (SSR-AA) | |||
| Control voltage | 3-32VDC | 90-250VAC | |||
| Control current | 6-25mA | 6-20mA | |||
| Load voltage | 22: 24-240VAC 38: 24-440VAC | ||||
| Load current | 10A, 15A, 20A, 25A, 30A, 40A, 60A, 80A, 100A | 1A | 5A | 2A、3A、4A | 10A, 15A, 20A, 25A, 30A, 40A, 60A, 80A, 100A |
| On-state voltage drop | ≤ 1.6VAC | DC ≤ 1.2V AC ≤ 1.6VAC | ≤ 1.6VAC | ||
| On-off time | ≤ 10ms | DC ≤ 5ms AC ≤ 10ms | ≤ 10ms | ||
| Off-state leakage current | ≤ 10mA | DC ≤ 5mA AC ≤ 10mA | ≤ 10mA | ||
| Dielectric strength | ≥ 2500VAC | ≥ 1500VAC | ≥ 2500VAC | ||
| Ambient temp. | -30~80°C | -30~80°C | -30~80°C | ||
| Dimension | 60×45×29mm | 32.5×17.5×18.5mm | 42×31×20mm | 34×26.5×18mm | 60×45×29mm |
| Installation form | Bolt installation | Dual line direct plug-in | Bolt installation | ||
| Instruction | A radiator must be installed for loads above 5A; a fan of strong cooling or water cooling must be added for loads above 80A | Installed next to well ventilated heat dissipation window | A radiator must be installed for loads above 5A; a fan of strong cooling or water cooling must be added for loads above 80A | ||
| HHG1-2 series | |
| Model | HHG1-2/032F-38 (SSR-DA) |
| Control voltage | 3-32VDC |
| Control current | Single circuit < 15mA |
| Load voltage | 38：24-440VAC |
| Load current | 10A, 15A, 20A, 25A, 30A, 40A(single-circuit) |
| On-state voltage drop | ≤ 1.6VAC |
| On-off time | ≤ 10ms |
| Off-state leakage current | ≤ 10mA |
| Dielectric strength | ≥ 2500VAC |
| Ambient temp. | -30~80°C |
| Dimension | 57×44×30mm |
| Installation form | Bolt installation |
| Instruction | A radiator must be installed for loads above 5A |
| HHG1-3 series | ||
| Model | HHG1-3/032F-38 (SSR-DA) | HHG1-3/250F-38 (SSR-AA) |
| Control voltage | 3-32VDC | 90-250VAC |
| Control current | 16-30mA | 8-30mA |
| Load voltage | 24-440VAC | |
| Load current | 10A, 15A, 20A, 25A, 30A, 40A, 60A, 80A, 100A, 120A | |
| On-state voltage drop | AC ≤ 1.6VAC | |
| On-off time | AC ≤ 10ms | |
| Off-state leakage current | AC ≤ 10mA | |
| Dielectric strength | ≥ 2500VAC | |
| Ambient temp. | -30~80°C | |
| Dimension | 106×75×40mm | |
| Installation form | Bolt installation | |
| Instruction | A radiator must be installed for loads above 5A; a fan of strong cooling or water cooling must be added for loads above 80A | |
