Input signal: Thermocouple: K, E; Thermal resistor: Cu50
Measurement error: ≤2.5 level
Adjustment method: Two-position relay contact on-off control
Setting method: Potentiometer setting
Working power supply: AC220V (other power supplies can be customized)
Dimensions: 48×48×106mm
Opening size: 45×45mm
Installation method: Panel type
Typical applications: Plastic sealing machine, sealing machine
TEG series | ||
Model | TEG-01 | TEG-02 |
Input signal | Thermocouple: K, E; thermal resistance: Cu50 | |
Measurement error | ≤ 2.5 class | |
Adjustment mode | Two-position relay contact on-off control | |
Setting mode | Potentiometer setting | |
Supply voltage | AC220V (other power supplies customizable) | |
Dimension | 48×48×106mm | |
Hole size | 45×45mm | |
Installation method | Panel type | |
Typical application | Plastic packaging machine, sealing machine |
